R-FUSE




Specifications                                                MF-MSMF                            MF-NSMF                             MF-SMDF



Package Style/Size                             Surface Mount/1812             Surface Mount/1206             Surface Mount/2018

Maximum Operating Voltage-                      60.0 - 6.0                             30.0 - 6.0                                  60.0

Vmax (Volts)



Maximum interrupt Voltage                               n/a                                       n/a                                       10.0

(Volts)

Maximum interrupt Current -                      100.0 - 10.0                         100.0 - 10.0                         40.0 - 10.0

Imax (Amps)

Hold Current - Ihold (Amps)                          0.10 - 2.60                           0.12 - 2.00                              0.55

Trip Current -Itrip (Amps)                              0.30 - 5.20                           0.29 - 4.00                              1.20

Device Resistance - Rmin                              0.015 - 0.15                         0.02 - 1.35                              0.20

(Ohms)

Device Resistance - Rmax                                    n/a                                       n/a                                     n/a

Device Resistance - R1max                          15.00 - 0.080                        6.00 - 0.085                             0.9

(Ohms)

Power Dissipation - Pd (Watts)                             0.8                                    0.7 - 0.4                                1.0






specifications MF-R small MF-R large MF-RX
Package Style/Size Radial Leaded Radial Leaded Radial Leaded
Maximum Operating Voltage - Vmax (Volts) 60.0 30.0 60.0
Maximum interrupt Voltage (Volts) n/a n/a n/a
Maximum interrupt Current - Imax (Amps) 40.0 40.0 40.0
Hold Current - Ihold (Amps) 0.05 - 0.9 0.9 - 11.0 1.1 - 3.75
Trip Current - Itrip (Amps) 0.1 - 1.8 1.8 - 22.0 2.2 - 7.5
Device Resistance - Rmin (Ohms) 7.3 - 0.14 0.7 - 0.003 0.15 - 0.03
Device Resistance - Rmax (Ohms) 11.0 - 0.3 0.12 - 0.1 0.25 - 0.05
Device Resistance - R1max (Ohms) 20.0 - 0.47 0.22 - 0.14 0.38 - 0.08
Power Dissipation - Pd (Watts) 0.22 - 1.0 0.6 - 4.5 1.5 - 3.2



Specifications MF-SM small MF-SM large MF-MSMD
Package Style/Size Surface Mount/2029 Surface Mount/3425 Surface Mount/1812
Maximum Operating Voltage -  Vmax (Volts) 60.0 - 15.0 & 6.0 33.0 - 15.0 60.0 - 6.0
Maximum interrupt Voltage (Volts) n/a n/a n/a
Maximum interrupt Current - Imax (Amps) 40.0 & 10.0 40.0 100.0 - 10.0
Hold Current - Ihold (Amps) 0.3 - 1.1 & 2.6 1.25 - 2.5 0.1 - 2.6
Trip Current - Itrip (Amps) 0.60 - 2.20 & 5.2 2.5 - 5.0 0.20 - 5.2
Device Resistance - Rmin (Ohms) 0.9 - 0.12 & 0.025 0.07 - 0.024 0.7 - 0.15
Device Resistance - Rmax (Ohms) n/a n/a n/a
Device Resistance - R1max (Ohms) 4.8 - 0.41 & 0.075 0.25 - 0.085 15.0 - 0.08
Power Dissipation - Pd (Watts) 1.7 1.9 - 1.7 0.8 - 1.5



Specifications MF-USMD MF-SMHT MF-SVS
Package Style/Size Surface Mount/1210 Surface Mount/2029 & 3425 Axial leaded Battery Strap
Maximum Operating Voltage - Vmax (Volts) 30.0 - 10.0 16.0 10.0
Maximum interrupt Voltage (Volts) n/a n/a n/a
Maximum interrupt Current - Imax (Amps) 100.0 - 40.0 100.0 100.0 - 10.0
Hold Current - Ihold (Amps) 0.05 - 1.10 1.36 - 1.60 1.7 - 2.3
Trip Current - Itrip (Amps) 0.15 - 2.2 2.72 - 3.20 4.1 - 5.2
Device Resistance - Rmin (Ohms) 2.08 - 0.05 0.104 - 0.50 0.018 - 0.01
Device Resistance - Rmax (Ohms) n/a n/a 0.32 - 0.18
Device Resistance - R1max (Ohms) 50.0 - 0.21 0.30 - 0.15 0.64 - 0.36
Power Dissipation - Pd (Watts) 0.6 2.1 2.1 - 2.6



specifications MF-VS MF-VS Narrow Body MF-LR
Package Style/Size Axial leaded Battery Strap Axial leaded Battery Strap Axial leaded Battery Strap
Maximum Operating Voltage - Vmax (Volts) 16.0 - 12.0 12.0 20.0 - 10.0
Maximum interrupt Voltage (Volts) n/a n/a n/a
Maximum interrupt Current - Imax (Amps) 100.0 100.0 100.0
Hold Current - Ihold (Amps) 1.7 - 2.4 1.7 - 2.1 1.9 - 6.0
Trip Current - Itrip (Amps) 3.4 - 5.9 3.4 - 4.7 3.9 - 11.7
Device Resistance - Rmin (Ohms) 0.03 - 0.14 0.018 - 0.030 0.039 - 0.007
Device Resistance - Rmax (Ohms) 0.041 - 0.026 0.030 - 0.052 0.072 - 0.014
Device Resistance - R1max (Ohms) 0.105 - 0.052 0.060 - 0.105 0.102 - 0.016
Power Dissipation - Pd (Watts) 1.4 - 1.9 1.4 - 1.5 1.2 - 2.8



Specifications MF-LS MF-S MF-D
Package Style/Size Axial leaded Battery Strap Axial leaded Battery Strap Disk
Maximum Operating Voltage - Vmax (Volts) 24.0 - 15.0 30.0 - 15.0 15.0
Maximum interrupt Voltage (Volts) n/a n/a n/a
Maximum interrupt Current - Imax (Amps) 100.0 100.0 50.0 - 10.0
Hold Current - Ihold (Amps) 0.7 - 3.4 1.2 - 4.2 2.5 - 12.2
Trip Current - Itrip (Amps) 1.5 - 6.8 2.7 - 7.6 n/a
Device Resistance - Rmin (Ohms) 0.10 - 0.016 0.085 - 0.012 0.45 - 0.37
Device Resistance - Rmax (Ohms) 0.20 - 0.027 0.16 - 0.24 0.30 - 0.017
Device Resistance - R1max (Ohms) 0.34 - 0.05 0.22 - 0.04 n/a
Power Dissipation - Pd (Watts) 1.0 - 2.7 1.2 - 2.9 n/a



Specifications MF-USMF
Package Style/Size Surface Mount/1210
Maximum Operating Voltage - Vmax (Volts) 6.0
Maximum interrupt Voltage (Volts) n/a
Maximum interrupt Current - Imax (Amps) 40
Hold Current - Ihold (Amps) 1.10
Trip Current - Itrip (Amps) 2.20
Device Resistance -    Rmin (Ohms) 0.05
Device Resistance - Rmax (Ohms) n/a
Device Resistance - R1max (Ohms) 0.21
Power Dissipation - Pd (Watts) 0.6



Specifications MF-RX/250 MF-SM/250 MF-RX/72
Package Style/Size Radial Leaded Surface Mount Radial Leaded
Maximum Operating Voltage - Vmax (Volts) 60.0 60.0 72.0
Maximum interrupt Voltage (Volts) 250.0 250.0 n/a
Maximum interrupt Current - Imax (Amps) 10.0 - 3.0 3.0 40.0
Hold Current - Ihold (Amps) 0.12 - 0.18 0.13 1.1 - 3.75
Trip Current - Itrip (Amps) 0.24 - 0.36 0.26 2.2 - 7.50
Device Resistance - Rmin (Ohms) 8.0 - 0.8 9.0 - 4.0 0.15 - 0.03
Device Resistance - Rmax (Ohms) 12.0 - 2.0 12.0 - 7.0 0.25 - 0.05
Device Resistance - R1max (Ohms) 16.0 - 4.0 20.0 0.38 - 0.08
Power Dissipation - Pd (Watts) 1.0 3.0 1.5 - 3.2



Specifications MF-R/90 MF-R/600
Package Style/Size Radial Leaded Radial Leaded
Maximum Operating Voltage - Vmax (Volts) 90.0 60.0
Maximum interrupt Voltage (Volts) n/a 600
Maximum interrupt Current - Imax (Amps) 10.0 3.0
Hold Current - Ihold (Amps) 0.55 - 0.75 0.15 - 0.16
Trip Current - Itrip (Amps) 1.1 - 1.5 0.30 - 0.32
Device Resistance - Rmin (Ohms) 0.14 - 0.007 9.0 - 4.0
Device Resistance - Rmax (Ohms) 0.9 - 0.75 12.0 - 7.0
Device Resistance - R1max (Ohms) 2.0 - 1.65 22.0 - 16.0
Power Dissipation - Pd (Watts) 2.0 1.0
